|Name:||Woven Bag Making Machine||Type:||UW-LT500|
|Material Unwinding Width:||550-1160mm||Production Speed:||40-80 Pcs/min|
|Bag Hight:||200-450mm||Bag Width:||180-500mm|
|Width Of Bag Gusset:||80-200mm||Length Of Bag Handle:||370-600m|
|Materil Basis Weight(thickness):||70-120/㎡||Total Power:||40KW|
non woven bag making machine automatic 80pcs Min,
ultrasonic sealing machine non woven bag,
ultrasonic machine for non woven bag
Primary Shaping Non Woven Box Bag Making Machine
This machine adopts mechanical, optical, letrical and pneumatic integration, tchnology. suitable for feeding the roll material of non woven fabric and laminated non woven fabric. It's a specialized equipment for making the primary shaping non woven (laminated) three-dimensional bag (no need to turn the bag inside out). This equipment features stable production, strong and decent senling of bags, good looking, top grade, fancy and reusable, mainly applied in the field of non woven wine packing, beverage packing, gift bags and hotel promotional bags etc.
This machine adopts LCD touch screen and equipped with stepping motor for fix length, photoelecric tracking, auto pstining, and auto rectifying deviation, which is accurate and stable, has the function of auto counting, auto handle sealing, auto bag pile and auto alarming when reach the setting numbers etc.It is the most advanced equipment for non woven bag market at present.
1. Feeding retifying deviation and edgefold adopt inelligent position adjustment,instead of traditional manual position adjustment by shaking the handwheel.We only need to set pararneters in the computer, whichis accurate to position and convenient to use. The normal edge folding range is 30-35 mm (adjust-ablel. Molds are controlled by the cylinder pressure, making welding clean and firm. Mold pattern can also be customized.
2. The creasing part moves back and forth with intelligent position adjustment instead of traditinal manual position adjustment by shaking the handwheel.We only need to set parameters in the computer according to the width of the bag, which is accurate to position and convenient to use. Driving the air knives to roll left and right can make finished bags more dimensional. The creasing width range also uses stepping type intelligent adjustable position.The range is 80-200mm equal to bag side width.
3. Hidden folding bag design, placed inthe body, delicate and flexible,is greatly saving space. The traditional bag-folding machine needs to be specially equipped and placed at he outlet of machine. Besides, it is bulky and inconve-nient to move back and forth to adjust the connection with the machine. The ingenious hidden design solves this problem.
4. The new type bag collecting machine adopts the visual operation of the computer display screen. According to the need, the pre-set quantity can be as many as one dozen, which is corvenient to collect neat bags.
Main configuration list :
|Material Unwinding Width||550-1160mm|
|Width of Bag Gusset||80-200mm|
|Length of Bag Handle||370-600mm|
|Material Basis Weight(thickness)||70-120/㎡|
1: Can you help us find any engineer in our location?
Of course, we will check and inform you as soon as possible.
2: How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock. It is according to quantity.
3: Does your engineer understand English?
Our engineer understand a little English. All our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.
4: How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.
5: How could we do after one year warranty period?
We also can do service for you, but you need pay salary for my technician 80USD/day.
6: How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.
7: What should we charge for your engineer?
You should charge for the cost of our engineer's visa , air tickets, hotel, food ,and also their salary 100USD one day per person.
8: Are you trading company or manufacturer?
We are factory.
9: How do we solve the machine problem after your engineer leaving?
Generally speaking, there will be no problem after finish installing. In case you have any problem. You can contact our sales at any time. Our engineer will take a solution video according to your description.
